3D Poster Experience
Investigating time domain waveform as close as possible from the transistor in a MMIC is a
quite new experience. It increases considerably research fields in
terms of testing and modeling. The use of a LSNA associated with high
impedance probes is
the much more suitable technical solution.
During a french symptosium in Toulouse (France), I compared this technical
vision to the add of a 3th dimension in a poster session : everything becomes so easy!
Some people discovered what is a LSNA just because of the poster architechture. Conclusion : funny and
effeciency is not a non sense!
|
The poster and I
|
|
|
A real HIP (high impedance probe) probing a false MMIC
|
The probe is connected with a real cable to a false LSNA
|
|
Then, one gets the results on a false computer screen
|
|
